Model |
XR-FSW500 |
XR-FSW750 |
XR-FSW1000 |
|
Laser power |
500W |
750W |
1000W |
|
The laser wavelength |
1070nm |
||
|
Processing wide |
500*500mm |
1300*900 |
1500*1000 |
|
The X axis stroke |
520mm |
1320mm |
1520mm |
|
Y trip |
520mm |
920mm |
1020mm |
|
The Z axis stroke |
60mm |
||
|
Positioning accuracy of X/Y axis |
±0.03mm/s |
||
|
Repeated positioning accuracy of X/Y axis |
±0.02mm/s |
||
|
Cutting speed and thickness |
It depends on the material |
||
|
The weight |
800KG |
1200KG |
1800KG |
|
The engine power |
<3.5KW |
<4.5KW |
<5.5KW |
|
Electricity demand |
380V/50Hz/60Hz/60A |
||
